Ashraf Nickel Alloys is a premier manufacturer and supplier based in Riyadh, Saudi Arabia, specializing in high-quality zirconium sheets and plates. With a commitment to excellence, we provide a comprehensive range of products tailored to meet diverse industrial needs, including petrochemical, oil and gas, and chemical processing applications. We are renowned for our exceptional service, cutting-edge technology, and stringent quality control, ensuring that our zirconium sheets and plates offer superior corrosion resistance, durability, and mechanical properties. Our expertise and dedication make us a trusted partner in the industry.
Zirconium sheets and plates typically consist of over 99.2% zirconium with minor traces of hafnium (up to 4.5%) due to their natural co-occurrence. Other impurities like oxygen, nitrogen, carbon, and iron are tightly controlled to enhance properties. Zirconium exhibits excellent mechanical properties, with a tensile strength of 330-580 MPa, yield strength of 200-400 MPa, and elongation of 14-40%, depending on the grade and treatment. These are highly ductile, heat-resistant materials with a low neutron absorption cross-section, ideal for nuclear, chemical processing, and aerospace applications. Their exceptional corrosion resistance further boosts their versatility.
| Standard Specification : | ASTM B551 / ASME SB551 |
| Dimensions : | ASTM, ASME, and API |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Zirconium and Zirconium Alloys Chemical Composition | |||||||||
| Products | Chemical Composition (wt%≤) | ||||||||
| Sn | Fe | Ni | Cr | Fe+Cr | Fe+Ni+Cr | Nb | Al | B | |
| R60001 Nuclear Grade Pure Zirconium (Zr-0) | 0.005 | 0.15 | 0.0070 | 0.02 | – | – | – | 0.0075 | 0.0005 |
| R60802 (Zr-2) | 1.20-1.70 | 0.07-0.20 | 0.03-0.08 | 0.05-0.15 | – | 0.18-0.38 | – | 0.0075 | 0.0005 |
| R60804 (Zr-4) | 1.20-1.70 | 0.18-0.24 | 0.0070 | 0.07-0.13 | 0.28-0.37 | – | – | 0.0075 | 0.0005 |
| R60901 (Zr-2.5Nb) | 0.0050 | 0.150 | 0.0070 | 0.02 | – | – | 2.4-2.8 | 0.0075 | 0.0005 |
| R60904 (Zr-2.5Nb) | 0.010 | 0.065 | 0.0035 | 0.01 | – | – | 2.5-2.8 | 0.0075 | 0.0005 |
| Products | Chemical Composition(wt%≤) | ||||||||
| Cd | Co | Cu | Hf | Mg | Mn | Mo | Si | Ti | |
| R60001 Nuclear Grade Pure Zirconium (Zr-0) | 0.0005 | 0.0020 | 0.0050 | 0.010 | 0.0020 | 0.0050 | 0.0050 | 0.0120 | 0.0050 |
| R60802 (Zr-2) | 0.0005 | 0.0020 | 0.0050 | 0.010 | 0.0020 | 0.0050 | 0.0050 | 0.0120 | 0.0050 |
| R60804 (Zr-4) | 0.0005 | 0.0020 | 0.0050 | 0.010 | 0.0020 | 0.0050 | 0.0050 | 0.0120 | 0.0050 |
| R60901 (Zr-2.5Nb) | 0.0005 | 0.0020 | 0.0050 | 0.010 | 0.0020 | 0.0050 | 0.0050 | 0.0120 | 0.0050 |
| R60904 (Zr-2.5Nb) | 0.0005 | 0.0020 | 0.0050 | 0.005 | 0.0020 | 0.0050 | 0.0050 | 0.0120 | 0.0050 |
| Products | Chemical Composition (wt%≤) | ||||||||
| U | V | W | C | N | H | O | |||
| R60001 Nuclear Grade Pure Zirconium (Zr-0) | 0.0035 | 0.005 | 0.010 | 0.027 | 0.0065 | 0.0025 | 0.09-0.16 | ||
| R60802 (Zr-2) | 0.0035 | 0.005 | 0.010 | 0.027 | 0.0065 | 0.0025 | 0.09-0.16 | ||
| R60804 (Zr-4) | 0.0035 | 0.005 | 0.010 | 0.027 | 0.0065 | 0.0025 | 0.09-0.16 | ||
| R60901 (Zr-2.5Nb) | 0.0035 | – | 0.010 | 0.027 | 0.0080 | 0.0025 | 0.09-0.15 | ||
| R60904 (Zr-2.5Nb) | 0.0035 | 0.005 | 0.010 | 0.027 | 0.0065 | 0.0025 | 0.01-0.14 | ||
| Zirconium and Zirconium Alloys Sheet & Plate Mechanical Properties | |||||
| Grades | |||||
| Products | R60700 | R60702 | R60704 | R60705 | R60706 |
| Tensile strength, min, ksi (MPa) | – | 55 (380) | 60 (415) | 80 (550) | 74 (510) |
| Yield strength, min, ksi (MPa) | – | 30 (205) | 35 (240) | 55 (380) | 50 (345) |
| Tensile strength, max, ksi (MPa) | 55 (380) | – | – | – | – |
| Yield strength, max, ksi (MPa) Sheet, Plate and Strip | 44 (305) | – | – | – | – |
| Elongation in 2 in. or 50 mm, min, % | 20 | 16 | 14 | 16 | 14 |
| Bend test radius | 5T | 5T | 5T | 3T | 2.5T |
At Ashraf Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Zirconium Sheets and Plates in Riyadh, Saudi Arabia, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Saudi Arabia, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Zirconium sheets and plates are widely used in various industries due to their exceptional corrosion resistance, high melting point, and biocompatibility. The chemical processing industry manufactures heat exchangers, reactors, and piping systems for handling aggressive chemicals. Zirconium’s low neutron absorption in the nuclear sector makes it ideal for fuel cladding and reactor components. The aerospace industry employs zirconium plates for high-temperature applications and advanced alloys. Additionally, zirconium sheets are utilized in medical implants, dental devices, and electronics for their biocompatibility and stability. Their durability and resistance to wear also make them suitable for industrial tooling.
