Ashraf Nickel Alloys stands out as a trusted **manufacturer and supplier of Manganese Bronze Sheets and Plates** in Riyadh, Saudi Arabia. They specialize in providing robust and high-strength copper alloy products tailored for both industrial and marine applications. Manganese bronze is celebrated for its remarkable wear resistance, toughness, and its ability to handle heavy loads even in corrosive environments. Ashraf Nickel Alloys ensures that their sheets and plates comply with international standards, catering to various sectors such as marine engineering, defense, construction, and heavy machinery across Saudi Arabia and the GCC.
Typically, Manganese Bronze Sheets and Plates are made up of copper (55–65%), with added elements like zinc, aluminum, manganese, and iron to boost strength and corrosion resistance. This alloy boasts impressive tensile strength—ranging from 480 to 885 MPa—while still being easy to machine and form. It excels in seawater and under heavy loads, providing a long service life with minimal upkeep. These sheets and plates come in hot-rolled, cold-rolled, and annealed forms, depending on what the application requires.
| Standard | JIS H3250-2006,ASTM B152M,GB/T2040-2008,ASTM B36,ASTM B194,ASTM B888, ASTM B19,ASTM B122,etc |
| Thickness | 0.1-120mm |
| Width | 2-2500mm |
| Length | 1m,2m,3m,6m,or as required |
| Surface | mill,polished,bright,mirror,hair line,brush,checkered,antique,sand blast,etc |
| Container size | 20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High) 40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High) 40ft HC:12032mm(Length)x2352mm(Width)x2698mm(High) |
| Application | Brass plate has a high corrosion resistance, and have good plasticity,in the air easy to cold and hot pressure processing,easy to welding, forging and tin, no stress corrosion cracking the tendency. |
| Cu(1) | Al | Fe | Pb | Mn | Sn | Zn | |
| Min./Max. | 57.0-60.0 | .25 | .8-2.0 | .20 | .05-.50 | .50-1.5 | Rem. |
| Nominal | 58.5 | – | 1.4 | – | .10 | 1.0 | 39.0 |
| ensile Strength, min | Yield Strength, at 0.5% extension under load, typ | Elongation, in 2 in. or 50 mm typ | Brinell Hardness (500 kg load) | Remarks | ||
|---|---|---|---|---|---|---|
| ksi | MPa | ksi | MPa | % | typical BHN | |
| 65 | 448 | 25 | 172 | 20 | 90 | |
In Riyadh, Ashraf Nickel Alloys’ Manganese Bronze Sheets and Plates find extensive use in shipbuilding, power generation, oil & gas, and heavy industrial sectors. Common applications include marine fittings, wear plates, pump components, bearing liners, and structural elements that face high friction or stress. With options for customized thicknesses, dimensions, and finishes, Ashraf Nickel Alloys guarantees that each product aligns with client specifications and industry standards, making them a dependable supplier of high-performance bronze materials in Saudi Arabia’s expanding industrial landscape.
Contact us to get a quick quote for your requirement.
Manganese bronze sheets and plates are widely used in marine and industrial engineering due to their excellent strength, corrosion resistance and durability Typical applications include shipbuilding, where they are used for propeller shafts and fittings, and gears and engine components in the automotive industry will be those encountered in severe environments They are also ideal for machines that heavy duty parts, valves, pumps and marine components. In addition, manganese lead is used for electrical components and structural components requiring high strength and corrosion resistance.
