Home > Aluminium Bronze Sheets and Plates
Ashraf Nickel Alloys, a top-notch manufacturer and supplier based in Riyadh, Saudi Arabia, specializes in high-quality Aluminium Bronze Sheets and Plates. These products are celebrated for their remarkable strength, resistance to corrosion, and durability. Crafted to adhere to strict international standards, they’re perfect for tough industrial applications across marine, chemical, petrochemical, and power generation sectors. Ashraf Nickel Alloys takes pride in their meticulous rolling and surface finishing processes, ensuring that each product boasts uniform thickness, outstanding mechanical properties, and dependable performance even in the harshest environments. With Aluminium Bronze Sheets and Plates, you get long-lasting, maintenance-free solutions that are a go-to choice for essential structural and fabrication needs.
These Aluminium Bronze Sheets and Plates primarily consist of copper, with aluminum as the key alloying element, often enhanced with small amounts of iron and nickel to boost strength and corrosion resistance. They showcase impressive tensile strength, excellent toughness, and remarkable resistance to wear, erosion, and corrosion, especially in seawater and aggressive chemical settings. These sheets and plates maintain their mechanical integrity under heavy loads and high temperatures, making them ideal for demanding applications. Their metallurgical properties allow for precise machining, forming, welding, and fabrication, making them incredibly versatile for industrial use.
| Specifications | ASTM B505 / ASME SB505, BS EN 10088-2, en 10028-7, IS 6911, AMS 4640, UNS C63000, UNS C95800, UZ19AL6, UNS C95510, AMS 4880 |
| Dimensions | MSRR, AMS, BS, JIS, AISI, ASTM, GB, DIN, EN, etc |
| Size Range | Cold Rolled : 0.5-6.4 mm Hot Rolled : 3.0–10.0 mm |
| Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Thickness | 0.3 mm to 120 mm |
| International Standard of Sheets | ASTM A480 ASTM A959 ASME IID EN ISO 9445 EN ISO 18286 EN 10051 EN 10088-1 ISO 15510 |
| Tolerances (width / thickness) | EN 10258/ DIN 59381 EN 10151 EN 10088 |
| Finish | 2B, 2D, BA NO (8), Cold rolled sheet (CR), Hot rolled plate (HR), SATIN (Met with Plastic Coated), No.1 finish hot rolled, 1D, 2B, No.4, BA, 8K, satin, mirror etc. |
| Hardness | Half Hard, Soft, Hard, Quarter Hard, Spring Hard |
| Form | Sheet, Plain Sheet, Flat Shim, Flat Sheet, Shim Sheet, Rolling Sheet, soft annealed, descaled, sheared, annealed |
| Value Added Service | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Profiling | Plasma Plate Cutting Laser Plate Cutting Oxy-propane Flame Cutting |
| Alloy | Aluminium | Iron | Nickel | Manganese | Zinc | Arsenic |
| CuAl5 | 4.0–6.5% | 0.5% max. | 0.8% max. | 0.5% max. | 0.5% max. | 0.4% max. |
| CuAl8 | 7.0–9.0% | 0.5% max. | 0.8% max. | 0.5% max. | 0.5% max. | |
| CuAl8Fe3 | 6.5–8.5% | 1.5–3.5% | 1.0% max. | 0.8% max. | 0.5% max. | |
| CuAl9Mn2 | 8.0–10.0% | 1.5% max. | 0.8% max. | 1.5–3.0% | 0.5% max. | |
| CuAl10Fe3 | 8.5–11.0% | 2.0–4.0% | 1.0% max. | 2.0% max. | 0.5% max. | |
| CuAl10Fe5Ni5 | 8.5–11.5% | 2.0–6.0% | 4.0–6.0% | 2.0% max. | 0.5% max. |
| Properties | Metric | Imperial |
| Hardness, Rockwell C | 27 | 27 |
| Tensile strength (M30 and O61 tempers) | 690 MPa | 100000 psi |
| Yield strength (M30 and O61 tempers) | 380 MPa | 55100 psi |
| Elongation at break (in 50 mm, 1% reduction in area) | 1.00% | 1.00% |
| Elastic modulus | 117 GPa | 17000 ksi |
| Compressive yield strength (at permanent set of 0.1%) | 450 MPa | 65300 psi |
| Compressive yield strength (at permanent set of 1%) | 880 MPa | 128000 psi |
| Poisson’s ratio | 0.34 | 0.34 |
| Charpy impact (@ 18.0 – 100°C/ -0.400 – 212°F, keyhole) | 3.00 J | 2.21 ft-lb |
| Izod impact (@ 18.0 – 100°C/ -0.400 – 212°F) | 3.00 J | 2.21 ft-lb |
| Fatigue strength (@# of cycles 1.00e+8, M30 temper) | 460 MPa | 66700 psi |
| Machinability (UNS C36000 (free-cutting brass) = 100) | 20 | 20 |
| Shear modulus | 42.3 GPa | 6140 ksi |
At Ashraf Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Aluminium Bronze Sheets and Plates in Riyadh, Saudi Arabia, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Saudi Arabia, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
You’ll find Aluminium Bronze Sheets and Plates widely utilized in marine engineering, shipbuilding, chemical processing facilities, offshore platforms, and power generation equipment. They’re perfect for crafting pump components, valve parts, propellers, structural elements, and bearing surfaces that come into contact with seawater and corrosive substances. By providing durable, high-performance aluminium bronze materials, Ashraf Nickel Alloys guarantees operational efficiency, reliability, and a long service life in critical industrial and marine applications.
