Ashraf Nickel Alloys stands out as a reliable **manufacturer and supplier of Phosphorous Bronze Sheets and Plates** in Riyadh, Saudi Arabia. They take pride in delivering top-notch copper alloy products that cater to a wide range of industrial needs. With a strong focus on precision and durability, Ashraf Nickel Alloys offers phosphorous bronze materials that are celebrated for their impressive wear resistance, corrosion resistance, and solid mechanical strength. The company serves various sectors, including electrical, marine, and engineering, ensuring that each sheet and plate adheres to strict quality standards. Thanks to their state-of-the-art manufacturing facilities and dependable delivery, Ashraf Nickel Alloys has become a go-to source for phosphorous bronze solutions across Saudi Arabia and the GCC region.
Phosphorous bronze sheets and plates are copper alloys, containing 0.5–11% tin and 0.01–0.35% phosphorus. Tin increases strength, corrosion resistance and wear, while phosphorus increases stability and reduces friction. These sheets exhibit excellent mechanical properties such as high tensile strength, good elasticity and fatigue resistance. They are robust, have excellent mechanical properties and exceptional corrosion resistance in marine and industrial applications. Advantages include reliability under load, resistance to damage and suitability for accurate applications, making it ideal for bearing springs and electrical connections in aerospace, automotive and manufacturing industries.
| Material | Phosphor Bronze Sheet/Plate |
| Grade | Alloy 510, Alloy 521, Alloy 519, Alloy 544 |
| Standard | ASTM B103 |
| Size | Thickness 0.1 mm to 50 mm; Width up to 500 mm; Length up to 2000 mm |
| Surface | Rolling surface, Chemical cleaned, Grinding |
| Element | Zinc (Zn) | Iron (Fe) | Tin (Sn) | Copper (Cu) | Lead (Pb) | Phosphorous (P) | Nickel (Ni) | Others |
|---|---|---|---|---|---|---|---|---|
| % | .00 – .20 | .00 – .10 | 4.50 – 5.50 | Balance | .00 – .02 | .01 – .40 | .00 – .20 | .00 – .20 |
| Tensile strength | Hardness | Elongation at break | Modulus of elasticity | Izod impact strength | Shear strength |
|---|---|---|---|---|---|
| 320 – 740 MPa | Brinell : 80 – 225 | < 60 % | 90 – 120 GPa | 62 J m⁻¹ | 250 – 430 MPa |
Typically, Phosphorous Bronze Sheets and Plates from Ashraf Nickel Alloys are made from copper mixed with about 0.3–0.7% phosphorous and 5–10% tin. This unique blend boosts the alloy’s strength, toughness, and resistance to corrosion, especially in marine and industrial settings. The material is known for its excellent fatigue resistance, good thermal and electrical conductivity, and outstanding wear properties. Depending on the temper, mechanical strength can vary, with tensile strengths usually falling between 300 to 600 MPa. These sheets and plates are easy to work with and promise a long service life, even in tough conditions.
Contact us to get a quick quote for your requirement.
In Riyadh’s electrical industry, Ashraf Nickel Alloys’ Phosphorous Bronze Sheets and Plates are commonly used for connectors, springs, and switches. They also find applications in marine settings, such as propellers, pump components, and valve parts. Their remarkable resistance to seawater corrosion makes them perfect for bearing and bushing materials. Plus, they’re popular in architecture and artistic metalwork due to their attractive finish and durability. Ashraf Nickel Alloys is committed to ensuring that all products meet customer expectations.
