Ashraf Nickel Alloys stands out as a top manufacturer and supplier of Super Duplex Needle Valves in Riyadh, Saudi Arabia. They specialize in precision-engineered valves that ensure accurate flow control and perform exceptionally well under high pressure. Crafted from Super Duplex stainless steel grades S32750 and S32760, these needle valves boast remarkable resistance to corrosion, pitting, and stress corrosion cracking. Known for their durability and reliability, they’re a go-to choice in industries where precise flow regulation and shut-off capabilities are crucial. Built to comply with ASTM, ASME, and international quality standards, these valves promise tight sealing, high tensile strength, and a long service life, even in tough chemical and marine settings.
Super Duplex Needle Valves are crafted from a cutting-edge duplex alloy that features around 25% chromium, 7% nickel, 4% molybdenum, and nitrogen, giving them double the strength of standard stainless steel. They deliver a tensile strength ranging from 800 to 1,000 MPa and a yield strength of about 550 MPa, ensuring they can handle high-pressure situations with ease. With outstanding resistance to chlorides, they excel in seawater, brine, and harsh chemical environments. These valves maintain their integrity in temperatures from -50°C to +300°C, resisting erosion, wear, and fatigue. Super Duplex Needle Valves are designed for industries that demand maximum precision, exceptional corrosion resistance, and a long operational life in challenging applications.
| VALVES SIZE | 6 MM TO 50 MM and 1/8″ TO 2″ |
| STANDARD | ASME B 16.10, BS1414/API 600, ASME B 16.5, BS EN 12266-1/API 598, ASME B 16.34, ASTM A890 4A, ASME B 16.25 |
| CONNECTION | TUBE END, THREADED, SOCKET WELD, BUTT WELD, FLANGED, WELD NIPPLE, SAE |
| THREAD | METRIC, BSPP, NPT, JIC, BSPT, UNF |
| FUNCTION | 2 , 5 , 4 , 3 WAY, |
| MATERIAL OF SEAL RING | PVDF, DELRIN, GRAPHITE, PTFE, PEEK, |
| PRESSURE RATING | 15000 , 3000, 1500 , 10000, 6000 , 20000 PSI |
| TEMPERATURE OF MEDIA | (-120* C – 500*C ) AS LIKE PRESSURE RANGE |
| STANDARD | DIN , ISO , API , ANSI , AWWA , ASME , MSS |
| MEDIA | AIR, CHEMICAL, GAS, WATER, STEAM, HOT WATER , HYDRAULIC OIL, COLD WATER, SEA WATER |
| TYPE OF BODY | BAR STOCK |
| EQUIVALENT BRANDS | OLIVER VALVES, PARKER, SWAGELOK, HAMLET, DK-LOK, HOKE |
| PACKING DETAILS | WOODEN PALLET, BOX PACKING |
| Grade | S32760 | S32750 |
| Mn | 1.00 max | 1.20 max |
| Fe | 57.61 min | 58.095 min |
| C | 0.05 max | 0.030 max |
| Si | 1.00 max | 0.80 max |
| S | 0.010 max | 0.020 max |
| P | 0.030 max | 0.035 max |
| Cr | 24.00 – 26.00 | 24.00 – 26.00 |
| Ni | 6.00 – 8.00 | 6.00 – 8.00 |
| Mo | 3.00 – 4.00 | 3.00 – 5.00 |
| N | 0.20 – 0.30 | 0.24 – 0.32 |
| Melting Point (°C) | 1350 |
| Density (lb/in 3) | 0.281 |
| Density (g/cm 3) | 7.8 |
| Melting Point (°F) | 2460 |
At Ashraf Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Super Duplex Needle Valve in Riyadh, Saudi Arabia, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Saudi Arabia, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Super Duplex Needle Valves find their place in various industries where precise flow control is vital, such as oil and gas processing, petrochemical plants, marine engineering, power generation, water treatment, and desalination facilities. Their sturdy design makes them ideal for instrumentation systems, chemical dosing lines, hydraulic systems, and high-pressure fluid control applications. Thanks to their reliable shut-off capability and resistance to corrosion, these valves are trusted in demanding environments, ensuring that operations run smoothly and efficiently.
