Ashraf Nickel Alloys is a leading manufacturer and supplier of Hastelloy ball valves in Riyadh, Saudi Arabia. Our Hastelloy round valves are designed to provide exceptional durability, excellent corrosion resistance and high temperature performance, making them ideal for challenging industrial environments Known for their flexibility in the harsh conditions these valves have medical, aerospace, marine, oil -Are perfect for gas and industrial applications We adhere to strict quality standards to ensure that each valve meets the stringent industry requirements for reliability and longevity. Choose Ashraf Nickel Alloys for superior Hastelloy round valves that provide outstanding performance and meet your specific needs with accuracy and quality.
Hastelloy ball valves provide exceptional corrosion resistance, especially in harsh chemical and high-temperature environments. They are highly durable and withstand oxidation, stress corrosion cracking, and erosion. The valves offer high strength and toughness, ensuring reliable performance and long-term stability. Their robust construction ensures consistent, leak-proof operation under extreme conditions. These properties make Hastelloy ball valves ideal for chemical processing, aerospace, marine, and oil and gas industries, providing dependable solutions in challenging applications.
| VALVE SIZE | 6 MM TO 50 MM and 1/8″ TO 2″ |
| STANDARD | ASME B 16.34, ASTM A494/ASME SA494, ASME B 16.5, ASME B 16.10, BS EN 12266-1/API 598, BS1414/ API 600, ASME B 16.25 |
| CONNECTION | TUBE END, THREADED, SOCKET WELD, BUTT WELD, FLANGED, WELD NIPPLE, SAE |
| THREAD | METRIC, BSPP, NPT, JIC, BSPT, UNF |
| FUNCTION | 2 , 5 , 4 , 3 WAY, |
| MATERIAL OF SEAL RING | PVDF, DELRIN, GRAPHITE, PTFE, PEEK, |
| PRESSURE RATING | 15000 , 3000, 1500 , 10000, 6000 , 20000 PSI |
| TEMPERATURE OF MEDIA | (-120* C – 500*C ) AS LIKE PRESSURE RANGE |
| STANDARD | DIN , ISO , API , ANSI , AWWA , ASME , MSS |
| MEDIA | AIR, CHEMICAL, GAS, WATER, STEAM, HOT WATER , HYDRAULIC OIL, COLD WATER, SEA WATER |
| TYPE OF BODY | BAR STOCK |
| EQUIVALENT BRANDS | OLIVER VALVES, PARKER, SWAGELOK, HAMLET, DK-LOK, HOKE |
| PACKING DETAILS | WOODEN PALLET, BOX PACKING |
| Grade | Mn | C | Co | S | Si | Cr | Ni | Mo | Fe | W |
| Alloy C22 | 0.50 max | 0.010 max | 2.5 max | 0.02 max | 0.08 max | 20 – 22.5 | Bal | 12.5 – 14.5 | 2 – 6 | 2.5 – 3.5 |
| Alloy C276 | 1.0 max | 0.010 max | 2.5 max | 0.03 max | 0.08 max | 14.5 – 16.5 | Bal | 15 – 17 | 4 – 7 | 3 – 4.5 |
| Element | Melting Point | Yield Strength (0.2%Offset) | Density | Tensile Strength | Elongation |
| Alloy C22 | 1399 °C (2550 °F) | Psi – 45000 , MPa – 310 | 8.69 g/cm3 | Psi – 1,00,000 , MPa – 690 | 45 % |
| Alloy C276 | 1370 °C (2500 °F) | Psi – 52,000 , MPa – 355 | 8.89 g/cm3 | Psi – 1,15,000 , MPa – 790 | 40 % |
At Ashraf Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Hastelloy Ball Valve in Riyadh, Saudi Arabia, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Saudi Arabia, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Hastelloy ball valves are used in a variety of complex industrial applications because of their excellent performance. They are ideal for the chemical, aerospace, marine and oil and gas industries, where corrosion resistance and long lasting high temperatures are required These valves handle aggressive chemicals, high pressure systems and temperature a handle the mouth well. Furthermore, they are used in power and petrochemical plants to provide reliable operation and long-term performance in severe and harsh environments
