Ashraf Nickel Alloys stands out as a reliable manufacturer and supplier of Super Duplex Ball Valves in Riyadh, Saudi Arabia. We offer top-notch valves crafted for exceptional durability and impressive corrosion resistance. Built to meet ASTM and ASME standards, our ball valves are made from Super Duplex stainless steel grades S32750 and S32760, ensuring they perform exceptionally well in harsh, corrosive, and high-pressure settings. Renowned for their strength, resistance to pitting, and ability to withstand stress corrosion cracking, these valves are perfect for industries like oil & gas, petrochemical, marine, and desalination plants. We provide precision-engineered, leak-proof, and long-lasting Super Duplex ball valves tailored for demanding industrial needs.
Super Duplex Ball Valves are crafted from a blend of approximately 25% chromium, 7% nickel, 4% molybdenum, and nitrogen, which gives them remarkable strength and corrosion resistance. They boast a tensile strength ranging from 800 to 1,000 MPa and a yield strength of around 550 MPa, making them nearly twice as strong as traditional austenitic stainless steels. With excellent resistance to chloride-induced stress corrosion cracking and pitting, these valves are reliable in seawater and aggressive chemical environments. They operate effectively across extreme temperatures (-50°C to +300°C), combining outstanding mechanical integrity, toughness, and resistance to erosion and fatigue for maximum longevity.
| VALVES SIZE | 6 MM TO 50 MM and 1/8″ TO 2″ |
| STANDARD | ASME B 16.10, BS1414/API 600, ASME B 16.5, BS EN 12266-1/API 598, ASME B 16.34, ASTM A890 4A, ASME B 16.25 |
| CONNECTION | TUBE END, THREADED, SOCKET WELD, BUTT WELD, FLANGED, WELD NIPPLE, SAE |
| THREAD | METRIC, BSPP, NPT, JIC, BSPT, UNF |
| FUNCTION | 2 , 5 , 4 , 3 WAY, |
| MATERIAL OF SEAL RING | PVDF, DELRIN, GRAPHITE, PTFE, PEEK, |
| PRESSURE RATING | 15000 , 3000, 1500 , 10000, 6000 , 20000 PSI |
| TEMPERATURE OF MEDIA | (-120* C – 500*C ) AS LIKE PRESSURE RANGE |
| STANDARD | DIN , ISO , API , ANSI , AWWA , ASME , MSS |
| MEDIA | AIR, CHEMICAL, GAS, WATER, STEAM, HOT WATER , HYDRAULIC OIL, COLD WATER, SEA WATER |
| TYPE OF BODY | BAR STOCK |
| EQUIVALENT BRANDS | OLIVER VALVES, PARKER, SWAGELOK, HAMLET, DK-LOK, HOKE |
| PACKING DETAILS | WOODEN PALLET, BOX PACKING |
| Grade | S32760 | S32750 |
| Mn | 1.00 max | 1.20 max |
| Fe | 57.61 min | 58.095 min |
| C | 0.05 max | 0.030 max |
| Si | 1.00 max | 0.80 max |
| S | 0.010 max | 0.020 max |
| P | 0.030 max | 0.035 max |
| Cr | 24.00 – 26.00 | 24.00 – 26.00 |
| Ni | 6.00 – 8.00 | 6.00 – 8.00 |
| Mo | 3.00 – 4.00 | 3.00 – 5.00 |
| N | 0.20 – 0.30 | 0.24 – 0.32 |
| Melting Point (°C) | 1350 |
| Density (lb/in 3) | 0.281 |
| Density (g/cm 3) | 7.8 |
| Melting Point (°F) | 2460 |
At Ashraf Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Super Duplex Ball Valve in Riyadh, Saudi Arabia, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Saudi Arabia, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Super Duplex Ball Valves find extensive use in oil & gas processing plants, offshore platforms, and subsea operations, thanks to their capability to manage high-pressure and highly corrosive fluids. They are vital in the chemical industry, desalination plants, pulp & paper sectors, marine systems, and water treatment facilities. These valves excel in applications that demand tight shut-off, low torque operation, and minimal leakage, even in challenging environments. Super Duplex Ball Valves are designed to meet the rigorous demands of various industries, ensuring reliability and efficiency in every application.
