Ashraf Nickel Alloys stands out as a reliable manufacturer and supplier of Inconel 625 Stud Bolts in Riyadh, Saudi Arabia. We provide top-notch fastening solutions tailored for industries that operate in tough and demanding conditions. These stud bolts are celebrated for their exceptional corrosion resistance, impressive mechanical strength, and long-lasting durability, making them a go-to choice in marine, offshore, aerospace, and chemical processing sectors. Crafted to meet international quality standards, our Inconel 625 Stud Bolts come in a variety of sizes, grades, and specifications, ensuring they deliver dependable performance in both high-pressure and high-temperature scenarios.
The composition of Inconel 625 Stud Bolts primarily includes nickel and chromium, with notable amounts of molybdenum and niobium. This distinctive alloy blend offers remarkable resistance to pitting, crevice corrosion, oxidation, and stress corrosion cracking caused by chlorides. On the mechanical side, they boast high tensile and yield strength, outstanding fatigue resistance, and excellent creep-rupture characteristics. They retain their toughness and structural integrity even in cryogenic conditions and at elevated temperatures, making them perfect for critical fastening tasks in challenging environments.
| Specification | ASTM F468, B166 / ASME SF468, SB166 |
|---|---|
| Size | M02 to M33, Custom Sizes |
| Length | 3 mm to 200 mm |
| Stud Bolt | UNF, BSW, BSF, METRIC, UNC, or as required |
| Standard | DIN 525, DIN 835, DIN 938, DIN 939, DIN 940, DIN 949-1, DIN 949-2, DIN 975, DIN 976, DIN 2509, BS 2693, BS 3692, BS 4439, IS 1862, IS 13178, ANSI/ASME B18.31.2, ANSI/ASME B16.5 |
| Form | Hex, Threading, Square, Round as per Gauge Etc. |
| Threads Configuration | ASME B1.1 2A/3A – 2B/3B Inch Unified Threads and B1.13M 6h-6G Metric Coarse Threads |
| Certification | Dual Certified As per ASTM & ASME Codes |
| Types | Stud Bolts, Fully Threaded Stud Bolts, Tap End Stud Bolts, Double End Stud Bolts, Stud Bolts with Reduced Shank, Reduced Shank, Flange Stud Bolts, Flange Bolting, Weld Studs |
| Threads | Unless otherwise specified, the threads shall be rolled or cut and tapped horizontally or vertically |
| Test Certificate | as per EN 10204 / 3.1 Manufacturer Test Certificate |
| Additional Certifications | PED 97/23/EC Certified, Merkblatt AD 2000 W2 Certified |
| Production process | M24-M100: hot forging, M2-M24: Cold Froging, for custom-made connecting element machining and CNC |
| Head drive of Stud Bolts | Six-Lobe, Phillips, Phillips/Slot, Slotted etc |
| Packing of Stud Bolts | IN BULK: canton, pallet, Small Boxs / carton / pallet, or customer request |
| Surface Coating | Ptfe Coated Phosphate Coating Teflon Coating Zinc Coating Hot Dipped Galvanizing Coating Cadmium Coating Xylon Coating |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 625 | 0.10 max | 0.50 max | 0.50 max | 0.015 max | – | 5.0 max | 58.0 min | 20.0 – 23.0 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 625 | 8.4 g/cm3 | 1350 °C (2460 °F) | Psi – 1,35,000 , MPa – 930 | Psi – 75,000 , MPa – 517 | 42.5 % |
At Ashraf Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Inconel 625 Stud Bolts in Riyadh, Saudi Arabia, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Saudi Arabia, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Inconel 625 Stud Bolts find extensive application in offshore oil and gas platforms, subsea equipment, heat exchangers, and refinery systems, where they often face exposure to seawater and harsh chemicals. The aerospace industry relies on them for jet engines, turbine assemblies, and exhaust systems, thanks to their ability to endure extreme stress and heat. Additionally, they are utilized in marine engineering, power generation facilities, pollution control systems, and chemical processing plants. With their exceptional strength, corrosion resistance, and versatility, Inconel 625 Stud Bolts ensure long-term reliability for demanding industrial applications.
