Ashraf Nickel Alloys stands out as a reliable manufacturer and supplier of Inconel 601 Stud Bolts in Riyadh, Saudi Arabia. We specialize in providing top-notch fastening solutions that are specifically designed to thrive in high-temperature and corrosive environments. Our stud bolts are well-known for their remarkable resistance to oxidation, scaling, and carburization, making them ideal for critical applications across various sectors, including aerospace, chemical processing, petrochemical, power generation, and marine industries. Crafted to meet international standards, our Inconel 601 Stud Bolts come in a variety of sizes, grades, and specifications, ensuring they deliver dependable performance and a long service life even in the toughest operating conditions.
These stud bolts are primarily made from nickel and chromium, with small amounts of iron and aluminum added to boost their oxidation resistance and mechanical strength. They showcase impressive tensile and yield strength, excellent creep resistance, and outstanding toughness across a broad temperature range. Thanks to their metallurgical stability, they maintain their performance in both oxidizing and reducing environments, making them a trustworthy choice for high-stress, high-temperature applications.
| Specification | ASTM F468, B166 / ASME SF468, SB166 |
|---|---|
| Size | M02 to M33, Custom Sizes |
| Length | 3 mm to 200 mm |
| Stud Bolt | UNF, BSW, BSF, METRIC, UNC, or as required |
| Standard | DIN 525, DIN 835, DIN 938, DIN 939, DIN 940, DIN 949-1, DIN 949-2, DIN 975, DIN 976, DIN 2509, BS 2693, BS 3692, BS 4439, IS 1862, IS 13178, ANSI/ASME B18.31.2, ANSI/ASME B16.5 |
| Form | Hex, Threading, Square, Round as per Gauge Etc. |
| Threads Configuration | ASME B1.1 2A/3A – 2B/3B Inch Unified Threads and B1.13M 6h-6G Metric Coarse Threads |
| Certification | Dual Certified As per ASTM & ASME Codes |
| Types | Stud Bolts, Fully Threaded Stud Bolts, Tap End Stud Bolts, Double End Stud Bolts, Stud Bolts with Reduced Shank, Reduced Shank, Flange Stud Bolts, Flange Bolting, Weld Studs |
| Threads | Unless otherwise specified, the threads shall be rolled or cut and tapped horizontally or vertically |
| Test Certificate | as per EN 10204 / 3.1 Manufacturer Test Certificate |
| Additional Certifications | PED 97/23/EC Certified, Merkblatt AD 2000 W2 Certified |
| Production process | M24-M100: hot forging, M2-M24: Cold Froging, for custom-made connecting element machining and CNC |
| Head drive of Stud Bolts | Six-Lobe, Phillips, Phillips/Slot, Slotted etc |
| Packing of Stud Bolts | IN BULK: canton, pallet, Small Boxs / carton / pallet, or customer request |
| Surface Coating | Ptfe Coated Phosphate Coating Teflon Coating Zinc Coating Hot Dipped Galvanizing Coating Cadmium Coating Xylon Coating |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 601 | 0.10 max | 1.0 max | 0.5 max | 0.015 max | 1.0 max | Balance | 58.0 – 63.0 | 21.0 – 25.0 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 601 | 8.1 g/cm3 | 1411 °C (2571 °F) | Psi – 80,000 , MPa – 550 | Psi – 30,000 , MPa – 205 | 30 % |
At Ashraf Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Inconel 601 Stud Bolts in Riyadh, Saudi Arabia, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Saudi Arabia, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Inconel 601 Stud Bolts find extensive use in industrial furnaces, heat treatment equipment, and combustion chambers, thanks to their ability to endure extreme heat and corrosive atmospheres. In chemical and petrochemical plants, they are utilized in reactors, piping systems, and catalyst supports that come into contact with aggressive chemicals. The aerospace industry relies on them for exhaust systems, turbine components, and structural assemblies. Power generation facilities also incorporate them in boilers, superheaters, and high-temperature piping. With their exceptional strength, heat resistance, and corrosion protection, Inconel 601 Stud Bolts are a dependable choice for critical fastening applications.
