Home > Nimonic 90 Sheet and Plates
Mehul Nickelalloys is a trusted manufacturer and supplier of high-quality Nimonic 90 Sheets and Plates in Riyadh, Saudi Arabia. Nimonic 90 is a nickel-based superalloy known for its excellent strength, oxidation resistance, and high-temperature stability, making it suitable for demanding applications in aerospace, gas turbines, and industrial sectors. These sheets and plates provide superior performance under extreme conditions, offering excellent mechanical properties such as high tensile strength and resistance to creep. We offer a wide range of Nimonic 90 products tailored to meet specific customer requirements, ensuring the highest standards of quality and reliability.
Ashraf Nickel Alloys stands out as a reliable manufacturer and supplier of Nimonic 90 Sheets and Plates in Riyadh, Saudi Arabia. They offer top-notch nickel-based alloys that are specifically designed to handle extreme service conditions. Nimonic 90 is a nickel-chromium-cobalt alloy that’s enhanced with titanium and aluminum, making it highly sought after for its remarkable mechanical strength, resistance to oxidation, and ability to withstand creep at high temperatures. These sheets and plates are meticulously crafted to meet international standards and find their place in industries like aerospace, gas turbines, nuclear power, and energy generation, where dependability and durability are paramount.
| Dimensions : | ASTM, ASME, and API |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Shims Thickness : | Range from .01″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Plate, Sheet and Strip : | BS HR 203, DIN 17750, AECMA PrEN2293, AECMA PrEN2302, AECMA PrEN2411, ISO 6208 |
| Grade | Ni | Cr | Co | Ti | Al | C | Si | Cu | Fe | Mn | B | S | Zr | Pb |
| Nimonic 90 | Bal | 18-21 | 15-21 | 2-3 | 1-2 | 0.2 max | 1.0 max | 0.2 max | 1.5 max | 1.0 max | 0.02 max | 0.015 max | 0.15 max | 0.0020 max |
| Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 1150 MPa | 725 MPa | 30% |
| Grade | Density | Specific Gravity | Specific Heat (Btu/lb/Deg F – [32-212 Deg F]) | Electrical Resistivity (microhm-cm (at 68 Deg F) | Melting Point (Deg F) |
| Alloy 90 | 8.18g/cm³ | 1370°C | 12.7 μm/m °C (20 – 100°C) | 82.5 kN/mm² | 213 kN/mm² 227 / 240 kN/mm² |
| 0.296 lb/in³ | 2500°F | 7.1 x 10-6 in/in °F (70 – 212°F) | 11966 ksi | 30894 ksi 32924 / 34810 ksi |
| STANDARD | WERKSTOFF NR. | UNS |
| Nimonic 90 | 2.4632 | N07090 |
The composition of Nimonic 90 Sheets and Plates includes nickel, chromium, and cobalt, along with titanium, aluminum, and carbon, which work together to boost their strength and thermal stability. This alloy boasts impressive tensile and yield strength, excellent fatigue resistance, and superior creep characteristics even at elevated temperatures. It also shows outstanding resistance to oxidation, scaling, and corrosion, making it perfect for long-term use in tough environments. Thanks to its stable microstructure, Nimonic 90 Sheets and Plates provide durability, toughness, and an extended service life in demanding industrial settings.
Contact us to get a quick quote for your requirement.
These sheets and plates are widely utilized in sectors that need high-performance materials capable of enduring extreme heat and stress. In aerospace, they’re found in turbine blades, exhaust systems, and various engine components. The power generation industry relies on them for gas turbines, steam turbines, and high-temperature boilers. They also play a crucial role in nuclear reactors, chemical processing facilities, and marine engineering, where resistance to corrosion and heat is essential. With their ability to ensure efficiency, safety, and reliability, these sheets and plates are vital for critical high-temperature applications.
