SMehul Nickelalloys is a reputable manufacturer and supplier of high-quality Nimonic 80A sheets and plates in Riyadh, Saudi Arabia. Nimonic 80A is a versatile nickel-chromium alloy known for its excellent strength, oxidation resistance, and durability at high temperatures. These properties make it ideal for demanding applications in aerospace, gas turbines, and industrial environments where performance and reliability are paramount. We offer a wide range of Nimonic 80A Sheets and Plates tailored to meet the specific needs of our customers, ensuring that they receive products that meet the highest quality standards.
Ashraf Nickel Alloys stands out as a top-notch manufacturer and supplier of Nimonic 80A Sheets and Plates in Riyadh, Saudi Arabia. They specialize in high-quality nickel-based alloys that are designed to perform exceptionally well in tough conditions. Nimonic 80A is a nickel-chromium alloy that’s reinforced with titanium, aluminum, and carbon, making it renowned for its impressive mechanical strength, resistance to oxidation, and ability to withstand creep at high temperatures. These sheets and plates are meticulously crafted to meet international standards and are highly regarded in industries like aerospace, power generation, gas turbines, and chemical processing, where durability and reliability are absolutely essential.
| Standards : | ASTM B637 / ASME SB637 |
| Dimensions : | ASTM, ASME, and API |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Shims Thickness : | Range from .01″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Plate, Sheet and Strip : | BS HR 203, DIN 17750, AECMA PrEN2293, AECMA PrEN2302, AECMA PrEN2411, ISO 6208 |
| Grade | Al | B | C | Cr | Co | Cu | Fe | Mn | Ni | P | Si | S |
| Nimonic 80A | 1 – 1.8 | 0.008 max | 0.1 max | 18 – 21 | 0.2 max | 0.2 max | 3 max | 1 max | Balance | 0.045 max | 1 max | 0.015 max |
| Grade | Condition | Ultimate Tensile Strength MPA | Yield Strength MPA | Elongation on 4D (min) | Hardness min |
| Nimonic 80A | Solution Annealed & Precipatation Treated (aged) | 994 | 616 | 20 | 300 HV |
| WEIGHT PER NIMONIC SHEET : | ||||
| THICKNESS IN MM | SIZE IN MM | WEIGHT KG/M2 | ||
| 2000 X 1000 | 2500 X 1250 | 3000 X 1500 | ||
| 0.18 | 2.88 | – | – | 1.44 |
| 0.20 | 3.20 | – | – | 1.60 |
| 0.22 | 3.52 | – | – | 1.76 |
| 0.24 | 3.84 | – | – | 1.92 |
| 0.27 | 4.32 | – | – | 2.16 |
| 0.28 | 4.48 | – | – | 2.24 |
| 0.32 | 5.12 | – | – | 2.56 |
| 0.38 | 6.08 | – | – | 3.04 |
| 0.44 | 7.04 | 11.00 | – | 3.52 |
| 0.50 | 8.00 | 12.50 | – | 4.00 |
| 0.56 | 8.96 | 14.00 | – | 4.48 |
| 0.63 | 10.08 | 15.75 | – | 5.04 |
| 0.75 | 12.00 | 18.75 | – | 6.00 |
| 0.88 | 14.08 | 22.00 | – | 7.04 |
| 1.00 | 16.00 | 25.00 | 36.00 | 8.00 |
| .1.13 | 18.08 | 28.25 | 40.00 | 9.04 |
| 1.25 | 20.00 | 31.25 | 45.00 | 10.00 |
| 1.38 | 22.03 | 34.50 | 50.00 | 72.00 |
| 1.50 | 24.00 | 37.50 | 54.00 | 12.00 |
| 1.75 | 28.00 | 43.75 | 63.00 | 14.00 |
| 2.00 | 32.00 | 50.00 | 72.00 | 16.00 |
| 2.25 | 36.00 | 56.25 | 81.00 | 18.00 |
| 2.50 | 40.00 | 62.50 | 90.00 | 20.00 |
| 2.75 | 44.00 | 68.75 | 99.00 | 22.00 |
| 3.00 | 48.00 | 75.00 | 108.00 | 24.00 |
| 3.25 | 52.00 | 81.25 | 117.00 | 26.00 |
| 3.50 | 56.00 | 87.50 | 126.00 | 28.00 |
| 3.75 | 60.00 | 93.75 | 135.00 | 30.00 |
| 4.00 | 64.00 | 100.00 | 144.00 | 32.00 |
| 4.25 | 68.00 | 106.25 | 153.00 | 34.00 |
| 4.50 | 72.00 | 112.50 | 162.00 | 36.00 |
| 5.00 | 80.00 | 125.00 | 180.00 | 40.00 |
| 5.50 | 88.00 | 137.50 | 198.00 | 44.00 |
| 6.00 | 96.00 | 150.00 | 216.00 | 48.00 |
| 6.50 | 104.00 | 162.50 | 234.00 | 52.00 |
| 7.00 | 112.00 | 175.00 | 252.00 | 56.00 |
| 7.50 | 120.00 | 187.50 | 270.00 | 60.00 |
| 8.00 | 128.00 | 200.00 | 288.00 | 64.00 |
| STANDARD | WERKSTOFF NR. | UNS |
| Nimonic 80A | 2.4952 | N07080 |
The composition of Nimonic 80A Sheets and Plates primarily includes nickel and chromium, along with carefully controlled amounts of titanium, aluminum, and carbon, which boost their thermal stability and mechanical characteristics. This alloy boasts remarkable tensile and yield strength, excellent fatigue resistance, and outstanding creep resistance even at elevated temperatures. With its impressive resistance to oxidation and scaling, it promises long-lasting stability in harsh environments. The well-balanced microstructure of Nimonic 80A Sheets and Plates ensures toughness and durability, making them a dependable choice for extreme service conditions and critical applications.
Contact us to get a quick quote for your requirement.
These sheets and plates find extensive use in various industries that demand materials with exceptional high-temperature strength and oxidation resistance. In the aerospace sector, they are utilized in turbine blades, exhaust systems, and engine components. The power generation industry relies on them for gas turbines, steam turbines, and high-pressure boilers. Additionally, they are commonly found in chemical processing plants, automotive exhaust systems, and nuclear power facilities, where exposure to corrosive environments and extreme heat is a regular occurrence. These sheets and plates are designed to deliver long-lasting performance, efficiency, and safety in challenging industrial applications.
