Ashraf Nickel Alloys is a well-respected manufacturer and supplier of top-quality Monel Coils based in Riyadh, Saudi Arabia. They cater to various industries by providing durable and corrosion-resistant solutions. These coils are crafted with precision and adhere to international quality standards, ensuring they perform reliably even in the toughest environments. Renowned for their impressive strength, toughness, and resistance to seawater and chemicals, Monel Coils find extensive use in marine, oil & gas, chemical, and power generation sectors. Ashraf Nickel Alloys is dedicated to delivering dependable products along with prompt service and customer-centric solutions.
Monel Coils consist of about 63–70% nickel and 20–29% copper, with trace amounts of iron, manganese, silicon, and carbon. This unique blend provides exceptional resistance to acids, alkalis, and corrosion from seawater. In terms of mechanical properties, Monel Coils boast a tensile strength ranging from 550–620 MPa, yield strength around 240–345 MPa, and an elongation of up to 35%. They maintain their toughness across a variety of temperatures, exhibit high hardness, and offer excellent fatigue resistance, making them a reliable choice for high-stress and corrosive environments.Monel coils are composed primarily of nickel (63-70%) and copper (28-34%), with small amounts of iron, manganese, and other elements. They exhibit excellent corrosion resistance, particularly in marine environments, and resist acidic and alkaline solutions. Monel coils are known for their high strength, durability, and resistance to stress corrosion cracking. Their properties include good thermal conductivity, high melting point, and ease of fabrication. These coils are advantageous for use in harsh environments where durability and resistance to corrosion are crucial.
| Specifications | ASTM B127 / ASME SB 127, BS EN 10088-2, en 10028-7, IS 6911 |
| Dimensions | MSRR, AMS, BS, JIS, AISI, ASTM, GB, DIN, EN, etc |
| Size Range | Cold Rolled : 0.5-6.4 mm Hot Rolled : 3.0–10.0 mm |
| Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Thickness | 0.3 mm to 120 mm |
| International Standard of Sheets | ASTM A480 ASTM A959 ASME IID EN ISO 9445 EN ISO 18286 EN 10051 EN 10088-1 ISO 15510 |
| Tolerances (width / thickness | EN 10258/ DIN 59381 EN 10151 EN 10088 |
| Finish | 2B, 2D, BA NO (8), Cold rolled sheet (CR), Hot rolled plate (HR), SATIN (Met with Plastic Coated), No.1 finish hot rolled, 1D, 2B, No.4, BA, 8K, satin, mirror etc. |
| Hardness | Half Hard, Soft, Hard, Quarter Hard, Spring Hard |
| Form | Sheet, Plain Sheet, Flat Shim, Flat Sheet, Shim Sheet, Rolling Sheet, soft annealed, descaled, sheared, annealed |
| Value Added Service | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Profiling | Plasma Plate Cutting Laser Plate Cutting Oxy-propane Flame Cutting |
| C | Mn | Si | S | Cu | Fe | Ni | |
| Monel Coils | 0.30 max | 2.00 max | 0.50 max | 0.024 max | 28.00 – 34.00 | 2.50 max | 63.00 min |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation | |
| Monel Coils | 8.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80,000 , MPa – 550 | Psi – 35,000 , MPa – 240 | 40 % |
At Ashraf Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Monel Coils in Riyadh, Saudi Arabia, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Saudi Arabia, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Monel Coils are widely utilized in industries that require outstanding corrosion resistance and mechanical reliability. In marine settings, they are used in shipbuilding, seawater piping systems, and heat exchangers. The oil and gas sector employs them for pipelines, pumps, and processing equipment that face harsh chemicals and extreme conditions. They are also essential in chemical processing plants for managing acidic and alkaline solutions. Furthermore, Monel Coils are applied in aerospace, power generation, and nuclear industries, where durability, strength, and a long service life are crucial for performance and safety.
