Ashraf Nickel Alloys stands out as a reliable manufacturer and supplier of Monel 400 Coils in Riyadh, Saudi Arabia. We pride ourselves on delivering high-quality solutions designed for durability and resistance in tough environments. Monel 400, a nickel-copper solid-solution alloy, is celebrated for its remarkable resistance to seawater, acidic, and alkaline conditions, along with its impressive mechanical properties. Our Monel 400 Coils are meticulously engineered to meet international standards, ensuring consistent performance, precise dimensions, and dependable reliability. These coils find extensive use in marine, chemical, and oil & gas industries, where exceptional corrosion resistance and strength are crucial for demanding service conditions.
Monel 400 Coils are made up of about 63% nickel and 28–34% copper, along with trace amounts of iron, manganese, and silicon. This unique composition grants them excellent resistance to seawater, hydrofluoric acid, and alkaline solutions. On the mechanical side, Monel 400 Coils boast high tensile and yield strength, remarkable toughness, and outstanding resistance to stress corrosion cracking and cavitation. They perform reliably across a wide temperature range, from sub-zero to elevated conditions. Their perfect blend of strength and corrosion resistance makes them ideal for challenging applications in harsh and corrosive environments.
Monel 400 Coils Specifications | ||
| Specifications | ASTM / ASME SB 127 | |
| Size | 1000 mm x 2000 mm, 1220 mm x 2440 mm, 1500 mm x 3000 mm, 2000 mm x 2000 mm, 2000 mm x 4000 mm | |
| Thickness | 0.1mm to 12 mm Thk | |
| Form | Coils, Foils, Rolls, Plain Coil, Shim Coil, Strip, Flats, Blank (Circle), Ring (Flange) | |
| Finish | Hot rolled Coil (HR), Cold rolled Coil (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) | |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. | |
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
| Monel 400 | 0.30 max | 2.00 max | 0.50 max | 0.024 max | 28.00 – 34.00 | 2.50 max | 63.00 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Monel 400 | 8.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80,000 , MPa – 550 | Psi – 35,000 , MPa – 240 | 40 % |
At Ashraf Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Monel 400 Coils in Riyadh, Saudi Arabia, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Saudi Arabia, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Monel 400 coils are versatile in various industrial applications due to their excellent corrosion resistance, especially in marine and acidic environments. They are commonly used in chemical processing, oil and gas industries, and aerospace components. The alloy’s high strength and resistance to seawater make it ideal for marine applications like pump shafts and valve components. Monel 400 is also used in heat exchangers marine engineering and as a component in high-temperature applications, where resistance to oxidation and high pressure is crucial.
