Ashraf Nickel Alloys, located in Riyadh, Saudi Arabia, stands out as a top manufacturer and supplier of **Inconel 600 Sheets and Plates**. They provide high-quality materials designed for industries that operate in extreme temperatures and corrosive settings. These sheets and plates are crafted for exceptional strength, durability, and resistance to oxidation, carburization, and stress-corrosion cracking. With a range of sizes, thicknesses, and finishes available, they are produced to meet international standards, ensuring precision, reliability, and a long lifespan for critical industrial applications.
| 600 Sheets & Plates Specifications | ASTM B168 / ASME SB168, BS EN 10088-2, en 10028-7, IS 6911 |
|---|---|
| 600 Sheets & Plates Dimension Standard | MSRR, AMS, BS, JIS, AISI, ASTM, GB, DIN, EN, etc |
| Alloy 600 Sheets & Plates Size Range | Cold rolled ASME SB168 Grade 600 Inconel Sheet 0.5-6.4 mm Hot rolled ASME SB168 Grade 600 Inconel Sheet 3.0–10.0 mm |
| 600 Inconel Sheets & Plates Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Inconel 600 Sheets & Plates Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Inconel 600 Sheets & Plates Thickness | 0.3 mm to 120 mm |
| International Standard of Inconel 600 Sheets & Plates | ASTM A480 ASTM A959 ASME IID EN ISO 9445 EN ISO 18286 EN 10051 EN 10088-1 ISO 15510 |
| Tolerances (width / thickness) of Inconel 600 Sheets & Plates | EN 10258/ DIN 59381) EN 10151 ASME SB168 600 Inconel Strips EN 10088 SA -240-600 Strips |
| Finish of Inconel 600 Sheets & Plates | 2B, 2D, BA NO (8), Cold rolled sheet (CR), Hot rolled plate (HR), SATIN (Met with Plastic Coated), No.1 finish hot rolled, 1D, 2B, No.4, BA, 8K, satin, hairline, brush, mirror etc. |
| Hardness | Half Hard, Soft, Hard, Quarter Hard, Spring Hard |
| Form | Sheet, Plate, Strip, Flats, Clad Plate, Coils, Foils, Plain Sheet, Flat Shim, Flat Sheet, Shim Sheet, Rolling Sheet, Rolling Plate, Rolls, Blank (Circle), soft annealed, descaled, tread plate, sheared, annealed, Checker Plate |
| Value Added Service | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Dealers & Distributor of | SAIL, ESSAR, JINDAL, TATA, BHUSHAN, INDIAN, POSCO, JISCO, TISCO, LISCO, BAOSTEEL IMPORTED material |
| Inconel 600 Profiling | Plasma Plate Cutting Laser Plate Cutting Oxy-propane Flame Cutting |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 600 | 0.15 max | 1.00 max | 0.50 max | 0.015max | 0.50 max | 6.00 – 10.00 | 72.00 min | 14.00 – 17.00 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 600 | 8.47 g/cm3 | 1413 °C (2580 °F) | Psi – 95,000 , MPa – 655 | Psi – 45,000 , MPa – 310 | 40 % |
At Ashraf Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Inconel 600 Sheets and Plates in Riyadh, Saudi Arabia, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Saudi Arabia, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
These sheets and plates find extensive use in **aerospace, petrochemical, chemical processing, power generation, nuclear, and oil & gas industries**. Common applications include heat exchangers, boilers, superheaters, furnace components, reactor parts, and high-temperature process equipment. Their blend of strength, corrosion resistance, and thermal stability makes **Inconel 600 Sheets and Plates** the go-to choice for industries that need durable and dependable materials for challenging applications.
