The composition of Incoloy 825 Forgings includes nickel, iron, and chromium, along with molybdenum and copper, which boost their corrosion resistance, mechanical strength, and thermal stability. They showcase impressive tensile and yield strength, outstanding creep and fatigue resistance, and maintain their toughness across a wide temperature range. Their metallurgical stability ensures they perform consistently in both oxidizing and reducing environments, making them ideal for high-stress and high-temperature applications.
| Specifications | ASTM B564, ASME SB564 |
|---|---|
| Standard | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr | Al | Ti |
| Incoloy 825 | 0.05 max | 1.00 max | 0.5 max | 0.03 max | 1.50 – 3.00 | 22.00 min | 38.00 – 46.00 | 19.50 – 23.50 | 0.02 max | 0.06 – 1.20 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation | |
| Incoloy 825 | 8.14 g/cm3 | 1400 °C (2550 °F) | Psi – 80,000 , MPa – 550 | Psi – 32,000 , MPa – 220 | 30 % |
At Ashraf Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Incoloy 825 Forgings in Riyadh, Saudi Arabia, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Saudi Arabia, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Incoloy 825 Forgings find extensive use in chemical reactors, piping components, and heat exchangers that are constantly exposed to aggressive chemicals. The marine and offshore industries utilize them in components and structural assemblies that face seawater exposure, while power generation facilities rely on them for boilers, superheaters, and high-pressure systems. In aerospace, they are used in turbine components, exhaust systems, and structural parts. Thanks to their exceptional blend of strength, corrosion resistance, and durability, Incoloy 825 Forgings offer a trustworthy solution for critical industrial applications that demand precision and reliability.
