Ashraf Nickel Alloys stands out as a top manufacturer and supplier of Hastelloy X Wire in Riyadh, Saudi Arabia, delivering high-quality wire solutions tailored for high-temperature and corrosive environments. Hastelloy X is a specialized nickel-chromium-iron-molybdenum alloy designed to resist oxidation and maintain strength under heat. Our Hastelloy X wire meets ASTM B572 and AMS standards, guaranteeing precision and reliability in demanding sectors like aerospace, chemical processing, petrochemicals, and power generation. Renowned for its excellent weldability and formability, it’s commonly used in heating elements, gas turbine engines, and furnace components. We also provide custom diameters and spool sizes to fit your project needs.
Hastelloy X wire is composed of 47% nickel, 22% chromium, 18.5% iron, and 9% molybdenum, along with small amounts of cobalt, manganese, and silicon to boost stability. It boasts remarkable oxidation resistance up to 1200°C and impressive stress rupture strength in high-heat settings. The wire has a tensile strength of about 690 MPa and a yield strength of 275 MPa, ensuring it remains ductile and tough even under extreme thermal cycling. Its excellent creep and oxidation resistance make it perfect for critical components, while its superior fabrication properties and thermal stability guarantee durability in harsh industrial applications.
| Standards : | ASTM B572, ASME SB572 |
| Dimensions : | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Wire : | Thickness starting from 0.05mm |
| Round bar size : | Diameter: 3-~800mm |
| Hex Bar size : | 2-100mm A/F |
| Flat bar size : | Thickness: 2 -100mm / Width: 10 to 500mm |
| Square bar size : | 4 to 100mm |
| Rectangular Bars Size : | 33 x 30mm to 295 x 1066mm |
| Hollow Bar : | 32mm OD x 16mm ID to 250mm OD x 200mm ID |
| Tolerance : | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Finish : | Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish |
| Grade | C | Mn | Si | C0 | S | Fe | Ni | Cr | Mo | P |
| Hastelloy X | 0.05 – 0.15 | 1.00 max | 1.00 max | 0.50 – 2.50 | 0.03 max | 17.00 – 20.00 | Balance | 20.50 – 23.00 | 8.00 – 10.00 | 0.04 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.22 g/cm³ | 1355°C | 655 MPa | 240 MPa | 35 % |
At Ashraf Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Hastelloy X Wire in Riyadh, Saudi Arabia, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Saudi Arabia, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Hastelloy X wire finds extensive use in gas turbine engines, aerospace components, combustion zones, furnace hardware, and petrochemical plants, where high heat and corrosive conditions are the norm. It’s perfect for heating elements, expansion joints, afterburner parts, and exhaust systems that require top-notch thermal stability. Chemical and petrochemical facilities rely on it for reactor vessels, reformer tubes, and catalyst supports to handle aggressive chemicals. In power generation, its reliability and performance make it a go-to choice for critical applications.
