Ashraf Nickel Alloys, a prominent manufacturer and supplier located in Riyadh, Saudi Arabia, is known for its top-notch tungsten foils. With a reputation built on precision, durability, and consistency, the company serves a variety of industrial sectors that require advanced materials. Their tungsten foils are crafted using cutting-edge technology, which guarantees exceptional thickness uniformity, superior purity, and a fantastic surface finish. Ashraf Nickel Alloys places a strong emphasis on quality control and customer-focused solutions, offering customized products for everything from small-scale applications to large industrial projects. Trusted by clients in the aerospace, electronics, and energy sectors, their tungsten foils blend reliability with performance, meeting strict international standards for even the most demanding environments.
Tungsten foil is primarily made up of over 99% tungsten (W), a refractory metal celebrated for its incredibly high melting point, density, and resistance to corrosion. Its mechanical properties include impressive tensile strength, excellent creep resistance at high temperatures, and significant hardness, making it perfect for extreme conditions. When rolled to thin gauges, tungsten foil is highly ductile and flexible, yet it maintains its structural integrity under both thermal and mechanical stress. It also boasts excellent thermal and electrical conductivity, low thermal expansion, and resistance to chemical attacks, making it an ideal choice for applications that require strength, stability, and durability in harsh operating conditions.
| Standard Specification : | ASTM B760 / ASME SB760 |
| Dimensions : | ASTM, ASME, and API |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
At Ashraf Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Nimonic Sheet and Plates in Riyadh, Saudi Arabia, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Saudi Arabia, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
| Thickness | Width | Length |
|---|---|---|
| 0.05-0.1 | 100 | L |
| 0.10-0.15 | 100 | 200 |
| 0.15-0.20 | 205 | 1000 |
| 0.20-0.25 | 300 | 1000 |
| 0.25-0.30 | 330 | 1000 |
| 0.30-0.50 | 350 | 1000 |
| 0.50-0.80 | 330 | 1000 |
| 0.80-1.0 | 330 | 1000 |
| 1.-1.50 | 300 | 1000 |
| 1.50-3.0 | 300 | 1000 |
| >3.0 | 300 | L |
Tungsten foils find their way into a wide range of industries thanks to their unique blend of high temperature resistance, density, and conductivity. In the electronics field, they are used as components in semiconductors, shielding, and contact materials. In aerospace and defense, tungsten foils are utilized for radiation shielding, counterweights, and heat-resistant components. They also play a role in medical devices, such as X-ray and radiation shielding, as well as in chemical processing equipment where corrosion resistance is crucial.
