Home > Rene 41 Foil
Ashraf Nickel Alloys, located in Riyadh, Saudi Arabia, has built a solid reputation as a reliable manufacturer and supplier of Rene 41 Foil. They specialize in high-quality nickel-based superalloy products designed to withstand extreme temperatures and high-stress situations. Renowned for their precision, durability, and outstanding resistance to oxidation and creep, the company caters to various industries, including aerospace, gas turbines, petrochemical, power generation, and nuclear sectors. Ashraf Nickel Alloys provides Rene 41 Foil in a range of thicknesses, widths, and specifications to suit different industrial needs. With state-of-the-art manufacturing facilities and rigorous quality control measures, they guarantee dependable performance, extended service life, and adherence to international standards.
Rene 41 Foil is primarily made up of nickel (about 50–55%), chromium (18–20%), cobalt (10–12%), and molybdenum (9–10%), along with smaller amounts of titanium, aluminum, and iron. This unique composition offers remarkable resistance to oxidation, thermal fatigue, and creep at high temperatures. In terms of mechanical properties, Rene 41 Foil showcases impressive tensile and yield strength, toughness, and stability, even when exposed to high-stress, high-temperature environments for extended periods. This makes it an excellent choice for demanding applications.
| Standard Specification : | AMS 5545, AMS 5712, AMS 5713, AMS 5800, EN 2.4973, GE B50T59, GE B50TF109, GE B50TF76, UNS N07041, Werkstoff 2.4973 |
| Dimensions : | AMS |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Mechanical & Physical Properties | 21°C | 427°C | 538°C | 649°C | 760°C | 871°C | 982°C |
|---|---|---|---|---|---|---|---|
| Ultimate Tensile Strength /MPa | 1261.7 | – | – | 1117 | 1048 | 710.2 | – |
| 0.2% Yield Strength /MPa | 820.5 | – | – | 765.3 | 751.5 | 579.2 | – |
| Elongation % | 21 | – | – | 14 | 14 | 11 | – |
| Coefficient of Thermal Expansion µm/m⁰C | – | 13.3 | 13.7 | 14.3 | 15.1 | 15.5 | 16.7 |
| Thermal Conductivity /kcal/(hr.m.°C) | – | 14.4 | 16.1 | 17.9 | 19.6 | 21.4 | – |
| Modulus of Elasticity / x105 MPa | – | 2 | 1.93 | 1.79 | 1.72 | 1.65 | 1.52 |
| Cr | Ni | Mo | Co | Al | Ti | B | C | Fe | Mn | Si | S | Cu | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MIN | 18.00 | — | 9.00 | 10.00 | 1.40 | 3.00 | 0.003 | — | — | — | — | — | — |
| MAX | 20.00 | Balance | 10.50 | 12.00 | 1.80 | 3.30 | 0.01 | 0.12 | 5.00 | 0.10 | 0.50 | 0.015 | 0.50 |
At Ashraf Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Nimonic Sheet and Plates in Riyadh, Saudi Arabia, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Saudi Arabia, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
| Grade | UNS | Workstoff | AMS | GE |
| Rene 41 | N07041 | 2.4973 | AMS 5545, AMS 5712, AMS 5713, AMS 5800 | GE B50TF109, GE B50TF76 |
You’ll find Rene 41 Foil commonly used in aerospace and jet engines, turbine components, nuclear reactors, and high-temperature industrial furnaces. It’s particularly well-suited for combustion chambers, exhaust systems, and heat shields, where resistance to creep, thermal cycling, and oxidation is crucial. Its ability to maintain mechanical integrity and resist corrosion under extreme conditions makes Rene 41 Foil an essential material in industries that require high-performance solutions for reliable and long-lasting operations.
