Ashraf Nickel Alloys stands out as a reliable **manufacturer and supplier of Nickel Alloy 200 Sheets and Plates** in Riyadh, Saudi Arabia. We specialize in providing high-purity nickel solutions that industries trust for their exceptional corrosion resistance and thermal stability. Nickel Alloy 200 is a commercially pure wrought nickel, boasting a minimum nickel content of 99.6%. It’s celebrated for its remarkable mechanical properties and its ability to withstand a variety of corrosive environments. Our products meet ASTM B162 and other international standards, catering to diverse sectors across Saudi Arabia and the GCC, including chemical processing, electronics, and marine industries.
| Nickel Alloy Sheets & Plates Specifications | ASTM B162 / ASME SB162, BS EN 10088-2, en 10028-7, IS 6911 |
|---|---|
| Nickel Alloy Sheets & Plates Dimension Standard | MSRR, AMS, BS, JIS, AISI, ASTM, GB, DIN, EN, etc |
| Nickel Alloy Sheets & Plates Size Range | Cold rolled ASME SB162 Grade 201 Nickel Alloy Sheet 0.5-6.4 mm Hot rolled ASME SB162 Grade 200 Nickel Alloy Sheet 3.0–10.0 mm |
| Nickel Alloy Sheets & Plates Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Nickel Alloy Sheets & Plates Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Nickel Alloy Sheets & Plates Thickness | 0.3 mm to 120 mm |
| International Standard of Nickel Alloy Sheets & Plates | ASTM A480 ASTM A959 ASME IID EN ISO 9445 EN ISO 18286 EN 10051 EN 10088-1 ISO 15510 |
| Tolerances (width / thickness) of Nickel Alloy Sheets & Plates | EN 10258/ DIN 59381) EN 10151 ASME SB162 200 Nickel Alloy Strips EN 10088 SA -240-400 Strips |
| Finish of Nickel Alloy Sheets & Plates | 2B, 2D, BA NO (8), Cold rolled sheet (CR), Hot rolled plate (HR), SATIN (Met with Plastic Coated), No.1 finish hot rolled, 1D, 2B, No.4, BA, 8K, satin, hairline, brush, mirror etc. |
| Hardness | Half Hard, Soft, Hard, Quarter Hard, Spring Hard |
| Form | Sheet, Plate, Strip, Flats, Clad Plate, Coils, Foils, Plain Sheet, Flat Shim, Flat Sheet, Shim Sheet, Rolling Sheet, Rolling Plate, Rolls, Blank (Circle), soft annealed, descaled, tread plate, sheared, annealed, Checker Plate |
| Value Added Service | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Dealers & Distributor of | SAIL, ESSAR, JINDAL, TATA, BHUSHAN, INDIAN, POSCO, JISCO, TISCO, LISCO, BAOSTEEL IMPORTED material |
| Nickel Alloy Profiling | Plasma Plate Cutting Laser Plate Cutting Oxy-propane Flame Cutting |
| Element | Ni+Co | Cu | Si | Mn | C | Mg | S | P | Fe |
|---|---|---|---|---|---|---|---|---|---|
| Nickel | 99.99 | 0.015 | 0.03 | 0.002 | 0.01 | 0.01 | 0.001 | 0.001 | 0.04 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Nickel | 8.9 g/cm3 | 1446 °C (2635 °F) | Psi – 67000 , MPa – 462 | Psi – 21500 , MPa – 148 | 45 % |
In Riyadh, Ashraf Nickel Alloys’ Nickel Alloy 200 Sheets and Plates are extensively utilized in chemical plants, petrochemical refineries, food processing facilities, and power generation plants. Their superior corrosion resistance makes them ideal for handling caustic solutions, salt solutions, and high-purity water systems. Additionally, they are frequently used in electrical components, anodes, heat exchangers, and structural parts that face harsh chemical environments. We offer these products in a variety of thicknesses, dimensions, and surface finishes to meet the specific needs of each application, ensuring quality, durability, and performance.
Contact us to get a quick quote for your requirement.
Nickel alloy 200 sheets and plates are used in various industrial applications due to their strength and corrosion resistance. They are ideal for medical devices, aerospace products and marine environments where durability is required. Their resistance to extreme temperatures and aggressive chemicals makes them suitable for use in the oil and gas industry. In addition, Nickel Alloy 200 sheets and plates are used in the electrical and petrochemical industries, providing reliable performance and durability under extreme conditions
